Overview
LZDC Series Variable-area Flowmeter with Metallic Measuring Tube can also be
called metal-tube rotameter, it has the following advantages, simple
construction and convenient maintain, wide adaption which can be used to
measure the flow of liquids and gas. Compared with glass-tube rotameter, this
type has the characteric of high temperature and pressure resistance, high
security, easily read, and etc. It also can be used to measure the flow of
corrosive medium and opaqueness medium. The meter pipe and flange are
made of lcrl8Ni9Ti or 18Ni12Mo2Ti. The floater is made of stainless steel. If the
floater and lining are both corrosion resistant, it is bag lining PTFE.
Working principle
Variable-area Flowmeter with Metallic Measuring Tube is made up of two parts,
flow sensor and flow indicator( picture 1) Floater is installed inside the conical
measuring pipe. Because of the function of the fluid, it can be shifted freely up
and down in the conical pipe. The biggest outer diameter of the floater and the
annular area of the tapered tube change with the location of the floater. When
the flow rate of the fluid is stable to one number, the floater is also in a dynamic
balance. By the flow indicator connected with the taper measuring tube, the
magnetic signal of the floater would be delivered by non-contact way, that is to
say, the indicator can detect and deal with the flow value by the way of
magnetism delivery and finally show the flow value by the pointer, which is
showed on the dial of. At the same time, LCD can also read the instantaneous or
the accumulated flow value, and output the standard two wire ( 4-20 ) mA signal
/HART protocol.
Meter Data
Meter Model |
LZDC |
||
Measuring medium |
Liquids,gas,steam |
||
Measuring range (100% flow-rate) |
Water:20℃ |
(10-300000)L/h,Particular requirement are acceptable |
|
Air:0.1013MPa, 20℃ |
(0.7-3000)m3/h, Particular requirement are acceptable |
||
Range ability |
1:10 |
||
Accuracy class |
Locally type |
Mechanical pointer index |
1.5,2.0,2.5 |
Digital display(battery powered,service life:2years) |
1.0,1.5,2.0,2.5 |
||
Remote Transmitting Type:show mechanical pointer index and Digital display (battery powered,service life:2 years) at the same time |
1.0,1.5,2.0,2.5 |
||
Medium temperature |
Locally type |
Mechanical pointer index |
-80℃~+300℃, Hightemperature: 400℃ |
Digital display(battery powered,service life:2years) |
-40℃~+150℃ |
||
Remote Transmitting Type:show mechanical pointer index and Digital display (battery powered,service life:2 years) at the same time
|
-40℃~+150℃, Hightemperature: 400℃ |
||
Ambient temperature |
Locally type |
Mechanical pointer index |
-40℃~+120℃ |
Digital display(battery powered,service life:2years) |
-20℃~+60℃ |
||
Remote Transmitting Type:show mechanical pointer index and Digital display (battery powered,service life:2 years) at the same time
|
-20℃~+60℃ |
||
Nominal pressure |
DN15~DN50 |
4.0MPa(biggest:DN15:32MPa, DN25:25MPa, DN50:20MPa) |
|
DN80~DN200 |
1.6MPa(biggest:DN80:10MPa, DN100:6.4MPa, DN125:4.0MPa, DN150:4.0MPa, DN200:2.5MPa, DN250:2.5MPa) |
||
Measuring tube |
Flange connection,standard:DIN2501、ANSI、HG20617/HG20615,according to order standard |
||
Cable connector |
M20×1.5 1/2”G 1/2”NPT 3/4”G 3/4”NPT |
||
Installment type |
vertical(end into top),horizontal ( left into right, right into left), top into end( piping), (end into side, side into side) |
||
Entrance straight pipe |
≥5D |
||
Exit Straight pipe |
≥250mm |
||
Protection Grade |
IP65 IP67(others needs to be explained when ordering) |
||
Anti-explosion Mark |
Ex ia Ⅱ CT1-T6 |
||
Ex d Ⅱ CT6 |
External form size & Flange size
Requirement of particular install size can also be made
Caliber(mm) |
H |
H1 |
B |
|||||
J1 J5 RF |
J2 |
J3 |
J4 |
J2 |
J3 |
J4 |
J3 J4 |
|
15 |
250 |
200 |
160 |
160 |
400 |
450 |
480 |
100 |
20 |
250 |
200 |
160 |
160 |
400 |
450 |
480 |
100 |
25 |
250 |
200 |
160 |
160 |
400 |
450 |
480 |
100 |
32 |
250 |
200 |
160 |
160 |
400 |
450 |
480 |
100 |
40 |
250 |
200 |
160 |
250 |
400 |
450 |
480 |
100 |
50 |
250 |
250 |
200 |
250 |
400 |
500 |
560 |
120 |
65 |
250 |
250 |
200 |
250 |
400 |
520 |
580 |
120 |
80 |
250 |
300 |
200 |
250 |
400 |
550 |
600 |
160 |
100 |
250 |
300 |
250 |
300 |
400 |
600 |
650 |
180 |
125 |
400 |
350 |
300 |
350 |
400 |
650 |
700 |
250 |
150 |
400 |
350 |
350 |
350 |
500 |
650 |
700 |
250 |
200 |
500 |
450 |
400 |
450 |
650 |
700 |
- |
300 |
250 |
500 |
500 |
400 |
550 |
800 |
750 |
- |
300 |
Caliber(mm) |
Flange size(standard ANSI B 16.5 150 IbRF) |
Caliber/pressure |
Flange size(Standard DIN 2501) |
||||||||||
DN |
D |
k |
d3 |
f |
n |
d2 |
DN/PN |
D |
k |
d3 |
f |
n |
d2 |
1/2〃 |
88.9 |
60.5 |
35.1 |
1.6 |
4 |
15.7 |
15/4.0 |
95 |
65 |
45 |
1.5 |
4 |
14 |
3/4〃 |
98.6 |
69.9 |
42.9 |
1.6 |
4 |
15.7 |
20/4.0 |
105 |
75 |
55 |
1.5 |
4 |
14 |
1〃 |
108.0 |
79.2 |
50.8 |
1.6 |
4 |
15.7 |
25/4.0 |
115 |
85 |
65 |
1.5 |
4 |
14 |
1-1/4〃 |
117.3 |
88.9 |
63.5 |
1.6 |
4 |
15.7 |
32/4.0 |
140 |
100 |
76 |
1.5 |
4 |
18 |
1-1/2〃 |
127.0 |
98.6 |
73.2 |
1.6 |
4 |
15.7 |
40/4.0 |
150 |
110 |
86 |
1.5 |
4 |
18 |
2〃 |
152.4 |
120.7 |
91.9 |
1.6 |
4 |
19.1 |
50/4.0 |
165 |
125 |
100 |
2.0 |
4 |
18 |
2-1/2〃 |
177.8 |
139.7 |
104.6 |
1.6 |
4 |
19.1 |
65/1.6 |
185 |
145 |
120 |
2.0 |
4 |
18 |
3〃 |
190.5 |
152.4 |
127.0 |
1.6 |
4 |
19.1 |
80/1.6 |
200 |
160 |
136 |
2.0 |
8 |
18 |
4〃 |
228.6 |
190.5 |
157.2 |
1.6 |
8 |
19.1 |
100/1.6 |
220 |
180 |
156 |
2.0 |
8 |
18 |
5〃 |
254.0 |
215.9 |
185.7 |
1.6 |
8 |
22.4 |
125/1.6 |
250 |
210 |
186 |
2.0 |
8 |
18 |
6〃 |
279.4 |
241.3 |
215.9 |
1.6 |
8 |
22.4 |
150/1.6 |
285 |
240 |
212 |
2.0 |
8 |
22 |
8〃 |
342.9 |
298.5 |
269.7 |
1.6 |
8 |
22.4 |
200/1.6 |
340 |
295 |
268 |
2.0 |
12 |
22 |
10〃 |
406.4 |
362.0 |
323.9 |
1.6 |
12 |
25.4 |
250/1.6 |
405 |
355 |
320 |
2.0 |
12 |
26 |
How to choose indicator
M1 indicator
● With magnetic coupling, the displacement of magnetic floater
in measuring tube can be transmitted into flow value directly, and
● Stamp forming of Stainless steel;
● Surface polishing Mechanical pointer can show the flow
immediately. It has compact and artistic structure.
M2 indicator
● It can be showed by pointer and dial system, and be outputted
by being transmitted into electrical signal.
● Digital integrated design-multifunctional flow board;
● Modular design. The combination of flow instructions in place,
long distance transmission, accumulation, and alarm are optional.
● LCD can show the instantaneous flow, cumulative flow and
percentile flow instantly;
● (4-20)mA two-wire superposition HART agreement digital
communications.
● Full- featured key operation and on- the- spot instrument
parameter settings.
● Manual operator/ PC configurable software remote
configuration.
The function of intrinsically safe and flameproof security;
● One or two whole-course adjustable threshold alarm switch
output (optional);
● Can be applied directly in high-temperature environment.
Modeling Code
1.Meter model : LZDC |
|||||||||||||||||||
2.diameter : code |
|||||||||||||||||||
Code |
015 |
025 |
040 |
050 |
080 |
100 |
125 |
150 |
200 |
250 |
|||||||||
DN |
15 |
25 |
40 |
50 |
80 |
100 |
125 |
150 |
200 |
250 |
|||||||||
3.Installment type |
|||||||||||||||||||
J 1 |
Vertically installed |
||||||||||||||||||
J 2 |
Horizontal installed |
||||||||||||||||||
J 3 |
End into side |
||||||||||||||||||
J 4 |
Side into Side |
||||||||||||||||||
J 5 |
Top into End |
||||||||||||||||||
4.Installment connection |
|||||||||||||||||||
F |
Flange (common specification are G B or D I N, H G, A N S I, J I S can be chosen) |
||||||||||||||||||
L |
Thread |
||||||||||||||||||
K |
Clamp sanitary type |
||||||||||||||||||
5.Measuring plpe's materials |
|||||||||||||||||||
R1 |
304(1Cr18Ni9Ti) |
||||||||||||||||||
R0 |
316(0Cr18Ni12Mo2Ti) |
||||||||||||||||||
R00 |
316L(00Cr17Ni14Mo2) |
||||||||||||||||||
RF |
304 with PTFE lining |
||||||||||||||||||
Others |
Hostelry,Titanium Alloy,Aluminum Alloy,Picks Alloy,Copper Alloy,etc. |
||||||||||||||||||
6.Indicator's type |
|||||||||||||||||||
M1 |
Locally indicator, Stainless steel compression molding,
Surface polishing wiredrawing processing, Sanitary
|
||||||||||||||||||
M2 |
Locally indicator, Aluminum compression molding, Polyurethane epoxy paint |
||||||||||||||||||
M3/ES4 |
Output type LCD (4-20 mA current) |
||||||||||||||||||
M2/ES4 |
Output type LCD (4-20 mA current) |
||||||||||||||||||
M2/HAPT |
Output type LCD (4-20 mA current), HART agreement digital
communication)
|
||||||||||||||||||
M2/B |
3.6 V Lithium battery supply, LCD show the instant flow and accumulated
flow rate.
|
||||||||||||||||||
7.Blast proof type |
|||||||||||||||||||
N |
No requirements for anti-explosion (omission) |
||||||||||||||||||
EXi |
Exib Ⅱ CT1-T6 |
||||||||||||||||||
EXd |
Exib Ⅱ CT6 |
||||||||||||||||||
8.Measuring Medium |
|||||||||||||||||||
L |
liquids |
||||||||||||||||||
G |
gas |
||||||||||||||||||
9.Measuring tube's additional function(optional) |
|||||||||||||||||||
T |
Temperature protection clip set |
||||||||||||||||||
10.Indicator's additional function(optional) |
|||||||||||||||||||
KG22 |
alarm atKE1's lower limit,alarm at KE2's upper limit |
||||||||||||||||||
KG23 |
alarm atK1's lower limit,alarm at K2's upper limit |
||||||||||||||||||
KG24 |
alarm atKR1's lower limit,alarm at KR2's upper limit |
||||||||||||||||||
11.High-temperature type (optional) |
|||||||||||||||||||
H1 |
Medium's temperature: 120°C--160°C |
||||||||||||||||||
H2 |
Medium's temperature: 160°C--250°C |
||||||||||||||||||
H3 |
Medium's temperature: 250°C--400°C |
① ② ③ ④ ⑤ ⑥ ⑧
Example LZDC /050/J1 /F/R1 /M2/L
①Metal-tube rotameter ②Dn50 ③Vertically installed type ④Flange connection
⑤304ss measuring tube ⑥M2 indicator ⑧Liquids
